ASTM D2794-93 Thermal Spray Coatings Piston Rod Salt Fog Resistance

ASTM D2794-93 Thermal Spray Coatings Piston Rod Salt Fog Resistance
ASTM D2794-93 Thermal Spray Coatings Piston Rod Salt Fog Resistance ASTM D2794-93 Thermal Spray Coatings Piston Rod Salt Fog Resistance ASTM D2794-93 Thermal Spray Coatings Piston Rod Salt Fog Resistance

Large Image :  ASTM D2794-93 Thermal Spray Coatings Piston Rod Salt Fog Resistance Get Best Price

Product Details:

Place of Origin: Changzhou, China
Brand Name: Magic Power
Model Number: AP20,AP30,AP40

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Packaging Details: Standard Export Package
Delivery Time: 15~60 days depends on product type
Payment Terms: L/C, T/T
Detailed Product Description
Rod Material: Carbon Steel Or Stainless Steel Body Strength: > 40MPa
Micro Hardness: 65 HRC
High Light:

metal spray coatings

,

ceramic spray coatings

ASTM D2794-93 Thermal Spray Coatings Piston Rod Salt Fog Resistance

Description:

High hardness, high temperature resistant, corrosion resistance, salt fog resistance
Anti-corrosion and salt spray test > 4000hrs
Macro hardness 65 HRC
Maximum temperature 540˚C
Bond strength > 40MPa
Standard: ASTM-C633 ,NEN-EU 5,NEN-ISO 4287,NEN-ISO 4287,ASTM D2794-93
NEN-ISO 4287,DIN50021-155,TNOCA02.8043


HYDROX AP20 Coating Technical Specifications


List of items HYDROX AP20 Standard
Typical coating composition Inc625-Cr2O3TiO2
Coating thickness Bottom ( Inc625) ≥150um
  Surface layer ( Cr2O3TiO2) ≥200um
Bond strength > 40MPa ASTM-C633
Maximum temperature 540˚C
Porosity < 2%
Macro hardness 65 HRC
Micro hardness > 1000HV200 NEN-EU 5
Surface Finish (Ra) 0.15um-0.4um NEN-ISO 4287
Surface Finish (Rz) < 4.5um NEN-ISO 4287
Shock Value > 2J ASTM D2794-93
RPK Material contact area > 80%,Depth 1,0um NEN-ISO 4287
Anti-corrosion and salt spray test > 4000hrs DIN50021-155
ECP(Drying) < -350mV
ECP(Semi-dry) < -350mV TNOCA02.8043
ECP(Wet) < -350mV


To apple ceramic coating on the equipment surface can have many benefits . Such as high hardness, high temperature resistant, corrosion resistance, salt fog resistance. Effect is much better than common electroplating. It works well in ocean industry, food machinery, water conservancy and hydropower, aerospace and other industries.
